Hyper-Tactile’s flexible sensor array is a bionic electronic skin system composed of high-density sensor units, enabling large-area coverage and curved surface conformity on flexible substrates. The array captures pressure distribution in real time to generate a "pressure map".
The ultra-thin flexible sensor array delivers outstanding bendability. It conforms perfectly to complex curved surfaces such as robot palms and smart seats, enabling large-area, non-intrusive coverage.
Boasting high integration and high sampling frequency, it supports real-time refresh rate up to 200 Hz. It generates refined pressure distribution cloud maps to precisely capture force distribution, center-of-pressure position and dynamic variations, meeting requirements for high-precision force control and safe interaction.
Sensor pitch, array layout, outline dimension and shape can be customized to fit various structural sections. Featuring high durability and wide operating temperature range, it operates stably under harsh conditions.
|
Parameter Item |
Parameter Value |
|---|---|
|
Materials |
PET, FPC |
|
Dimensions |
Customizable |
|
Thickness |
≤ 0.3 mm |
|
Minimum Bending Radius |
≤ 1 mm |
|
Pressure Range |
1 kPa – 200 kPa |
|
Operating Power Consumption |
100 µA level |
|
Operating Voltage |
Wide voltage: 1.8 V – 18 V |
|
Operating Temperature |
-40 ℃ – 85 ℃ |
|
Hardware Interface |
Customizable: FPC, pin headers, etc. |
|
Ingress Protection Rating |
IP65 |
|
Repeatability |
CV＜5% |
|
Sensor Pitch |
≥ 2.4 mm |
|
Static Drift |
Baseline drift＜0.5 %/h |
|
Temperature Sensing |
Optional |
|
Slip Sensing |
Optional |
|
Capacitive Tactile Sensing |
Optional |
|
Pressure Sampling Frequency |
0 – 200 Hz |
|
Pressure Resolution |
12 bit |
